The influence of the back electromotive force of a motor on its performance

Precautions for motor operation

If the motor stops rotating due to excessive mechanical resistance during operation, there will be no back electromotive force, and the coil with low resistance will be directly connected to both ends of the power supply, causing a large current and easily burning out the motor. This state is encountered in motor testing, such as the stall test, which requires the motor rotor to be in a stationary state. At this time, the motor is very large and can easily burn out. Currently, most motor manufacturers use instantaneous value collection for stall testing, which basically avoids the problem of motor burning out due to long stall time. However, due to various factors such as assembly, the collected values have significant differences and cannot accurately reflect the starting state of the motor.

When the voltage of the power supply connected to the motor is much lower than the normal voltage, the motor coil does not rotate, there is no back electromotive force generated, and the motor is also easily burned out. This problem often occurs in motors used with temporary power lines. For example, temporary power lines use aluminum core wires because they are disposable and to prevent theft. Due to cost control, the voltage drop on the line is large, resulting in insufficient input voltage to the motor. The natural back electromotive force is relatively small, and in severe cases, the motor is difficult to start, even unable to start. Even if the motor starts, it is running at high current in an abnormal state, making it easy for the motor to be burned out.

Reverse electromotive force is generated by the tendency of the current in the resistance winding to change in magnitude. The situation of generating back electromotive force includes: (1) alternating current flowing into the coil; (2) The conductor is placed in an alternating magnetic field; (3) Conductor cutting magnetic field. During the operation of electrical appliances such as relay coils, solenoid valves, contactor coils, and motor windings, there is a phenomenon of induced electromotive force.

The physical meaning of back electromotive force: The electromotive force that opposes the passage or change of current is called back electromotive force. In the energy conversion equation UIt=ε inverse It+I2Rt, UIt is the input electrical energy, such as the input electrical energy to a battery, motor, or transformer; I2Rt is the heat loss energy in each circuit, which is a type of heat loss energy, the smaller the better; The difference between the input electrical energy and the heat loss consumption energy is the portion of useful energy ε that corresponds to the back electromotive force. In other words, the back electromotive force is used to generate useful energy and is inversely correlated with heat loss. The larger the heat loss energy, the smaller the achievable useful energy.

The factors that determine the back electromotive force: For motor products, the number of stator winding turns, rotor angular velocity, magnetic field generated by rotor magnets, and air gap between the stator and rotor are the factors that determine the back electromotive force of the motor. When the motor design is completed, both the rotor magnetic field and the number of turns of the stator winding are determined. Therefore, the only factor that determines the back electromotive force is the rotor angular velocity, also known as the rotor speed. As the rotor speed increases, the back electromotive force also increases. The difference between the inner diameter of the stator and the outer diameter of the rotor will affect the magnetic flux of the winding, and thus also affect the back electromotive force.

The generation of steady-state current requires two essential conditions: first, closing the conductive circuit. Secondly, the back electromotive force. We can understand the phenomenon of generating induced electromotive force from induction motors: a three-phase symmetrical voltage is applied to the stator winding of a motor with a mutual difference of 120 degrees, generating a circular rotating magnetic field. The rotor bars placed in this rotating magnetic field are subjected to electromagnetic force, transforming from stationary to rotating motion. Induced potential is generated inside the bars, and induced current flows through the closed circuit of the bars connected by the conductive end rings. In this way, an electric potential or electromotive force is generated inside the rotor conductor, which is called the back electromotive force. In a wound rotor motor, the open circuit voltage of the rotor is a typical back electromotive force.

The magnitude of the back electromotive force varies significantly for different types of motors. The magnitude of the back electromotive force of asynchronous motors is constantly changing with the size of the load, resulting in significant differences in efficiency indicators under different load conditions; In permanent magnet motors, as long as the speed remains constant, the magnitude of the back electromotive force remains constant, so the efficiency index under different load conditions remains basically unchanged.

Objectively speaking, the back electromotive force consumes the electrical energy in the circuit, but it is not a "loss". The portion of electrical energy corresponding to the back electromotive force will be converted into useful energy for electrical devices, such as the mechanical energy of electric motors and the chemical energy of batteries.

From this, it can be seen that the magnitude of the back electromotive force indicates the strength of the ability of the electrical device to convert the total input energy into useful energy, reflecting the level of the electrical device's conversion ability.
